YTH8321R1002/U VisionPRO 8000 RedLINK Kit with IAQ Contacts and Internet Gateway
YTH8321R1002/U VisionPRO 8000 RedLINK Kit with IAQ Contacts and Internet Gateway
YTH8321R1002/U VisionPRO 8000 RedLINK Kit with IAQ Contacts and Internet Gateway
YTH8321R1002/U VisionPRO 8000 RedLINK Kit with IAQ Contacts and Internet Gateway

YTH8321R1002/U VisionPRO 8000 RedLINK Kit with IAQ Contacts and Internet Gateway

Part #
YTH8321R1002/U
UPC
085267364744
$362.19

Available · ships in 1–2 business days

Free shipping to the contiguous US. No minimum.

Finish
Arctic White

Full specifications 7 manufacturer documents

  • 30-day returnsWithin 30 days, in the original packaging
  • Help from real peopleCall or email us before or after you order
  • Secure checkoutCard details never touch our servers
Need help matching a part?Call +1 (219) 319-0174 · Mon–Fri, 8 am – 5 pm ET

Product details

YTH8321R1002/U — VisionPRO 8000 RedLINK Kit with IAQ Contacts and Internet Gateway.

Smart Wi-Fi, programmable, non-programmable and line-voltage thermostats. Check your system type (conventional, heat pump, millivolt or line voltage) and whether you have a C-wire.

Specifications

Part Number YTH8321R1002/U
Application Conventional Systems, Heat Pumps with Auxiliary Heat
Thermostat Type Programmable, Digital, Low Voltage, RedLINK
Smart Home Integration No
Display Type Touch Screen
Display Size 10 sq in
Touchscreen Yes
Modes of Operation Heat, Off, Cool, Auto, Emergency Heat except model TH8110R1008
Program Type 7-Day Programmable, Manual / Not Programmed
Energy Star Certified Yes
Power Supply Hardwired
Battery Type Alkaline
Number of Batteries 4
Battery Life 1 Years
Battery Size AA
Manufacturer Warranty 5 Years
Includes TH8321R1001 VisionPRO® 8000 thermostat, THM6000R7001 RedLINK® Internet Gateway
For Use With Works standalone or with optional THM5421R1021 Equipment Interface Module and RedLINK® accessories
Communication Type RedLINK, WiFi
WiFi No
WiFi Specifications Internet Gateway THM6000R7001/U Provides WiFi Capabilities
Z-Wave No
Z-Wave Specifications Not Applicable
RedLINK Yes
Color Arctic White
Ambient Operating Temperature (Max) 120 °F, 49 °C
Ambient Operating Temperature (Min) 32 °F, 0 °C
Operating Relative Humidity (Max) 90% Non-condensing
Operating Relative Humidity (Min) 5% Non-condensing
Backlight Options Adjustable
Fan Function On, Auto, Circulating
Clock Type Year Clock
Demand Response No
Electrical Connection Type Screw terminals
Mounting Type Horizontal Mount
Number of Fan Speeds 2
Power Supply Frequency 50 Hz, 60 Hz
Mounting Location Wall, Internal
Product Height 4.63 in, 118 mm
Product Width 4.94 in, 126 mm
Product Depth 1.13 in, 29 mm
Hazmat Information LI metal Button Cell contained in Equipment *No Label is required*
Features ENERGY STAR Certified
UPC 085267364744
Country of Origin MX
Product Features Standard display size 3.75 sq. in.

Ratings & details

  • Standard display size 3.75 sq. in
  • Portable Comfort Control (REM5000R1001/U)

Manufacturer documents
