VR9205R2363T/U Direct Ignition Gas Valve for Pneumatic Furnace Modulation
- Part #
- VR9205R2363T/U
- UPC
- 085267702447
- Type
- Gas Valves
$199.46
Available · ships in 1–2 business days
Free shipping to the contiguous US. No minimum.
Delivery estimate
- Order
- Ships
- Arrives
Estimate for ground shipping within the contiguous US.
- Finish
- Gray, Black
Full specifications 3 manufacturer documents
Gas, electrical and venting work should be done by a licensed professional.
- 30-day returnsWithin 30 days, in the original packaging
- Help from real peopleCall or email us before or after you order
- Secure checkoutCard details never touch our servers
Product details
VR9205R2363T/U — Direct Ignition Gas Valve for Pneumatic Furnace Modulation.
Gas valves, ignition modules, igniters, flame sensors, thermocouples and oil primary controls. Match fuel type, voltage and inlet/outlet size.
Specifications
| Part Number | VR9205R2363T/U |
|---|---|
| Application | Modulating Valve |
| Ignition Type | Direct Burner Ignition |
| Type of Fuel | Natural Gas |
| Capacity (Max) | 200,000 BTU/h |
| Operating Voltage | 24 V AC |
| Inlet Connection Size | 1/2 in |
| Outlet Connection Size | 1/2 in |
| Regulation Type | Modulating |
| Pressure Rating | 1/2 psi, 3.5 kPa |
| Operating Pressure (Max) | 1/2 psi |
| For Use With | Gas Air Valve |
| Valve Body Pattern | Straight Through |
| Ambient Operating Temperature (Max) | 175 °F, 79 °C |
| Ambient Operating Temperature (Min) | 40 °F, -40 °C |
| Approvals and Standards | CSA Certified: LR112491 |
| Color | Gray, Black |
| Mounting Type | 0° to 90° in any direction from the upright position of the gas control knob, including vertically |
| Operating Frequency | 50 Hz, 60 Hz |
| Product Height | 4.04 in, 103 mm |
| Product Width | 5.04 in, 128 mm |
| UPC | 085267702447 |
| Country of Origin | MX |
