V8043F5093/U Zone Valve, 3/4 in Sweat, 8 Cv, 8 psi Close-Off, 300 psi Static

V8043F5093/U Zone Valve, 3/4 in Sweat, 8 Cv, 8 psi Close-Off, 300 psi Static

Part #
V8043F5093/U
UPC
085267833585
$165.64

Available · ships in 1–2 business days

Free shipping to the contiguous US. No minimum.

Material
Brass
Connection
Sweat
Finish
Brass

Full specifications 6 manufacturer documents

Gas, electrical and venting work should be done by a licensed professional.

  • 30-day returnsWithin 30 days, in the original packaging
  • Help from real peopleCall or email us before or after you order
  • Secure checkoutCard details never touch our servers
Need help matching a part?Call +1 (219) 319-0174 · Mon–Fri, 8 am – 5 pm ET

Product details

V8043F5093/U — Zone Valve, 3/4 in Sweat, 8 Cv, 8 psi Close-Off, 300 psi Static.

Motorized 2-way and 3-way zone valves, replacement heads and actuators that let one boiler heat several zones independently.

Specifications

Part Number V8043F5093/U
Valve Ball Material Buna-N (NBR) Rubber
Color Brass
Includes End switch enclosure, Manual Opener
Product Height 4.38 in, 111 mm
Product Length 2.38 in, 60 mm
Product Width 3.69 in, 89 mm
Manufacturer Warranty 1 Year
Ambient Operating Temperature (Max) 125 °F, 52 °C
Connection Type Sweat
Differential pressure for close-off (Max) 8 psi, 55 kPa
Flow Coefficient 8 Cv; 6.9 Kvs
Media Temperature (Min) 50 °F, 10 °C
Media Temperature (Max) 200 °F, 93 °C
Static Pressure Rating 300 psi, 2068 kPa
Valve Body Material Brass
Valve Body Pattern Two-way, Straight Through
Valve Plug Material Buna-N (NBR) Rubber
Valve Seat Material Brass
Valve Start Position Closed
Valve Stem Material Stainless Steel
UPC 085267833585
Country of Origin HU
