Part #
TH8321R1001/U
UPC
085267770439
$316.29

Available · ships in 1–2 business days

Free shipping to the contiguous US. No minimum.

Finish
Arctic White

Full specifications 7 manufacturer documents

  • 30-day returnsWithin 30 days, in the original packaging
  • Help from real peopleCall or email us before or after you order
  • Secure checkoutCard details never touch our servers
Need help matching a part?Call +1 (219) 319-0174 · Mon–Fri, 8 am – 5 pm ET

Product details

TH8321R1001/U — VisionPRO 8000 Thermostat with RedLINK and IAQ Contacts, 7-Day Programmable.

Smart Wi-Fi, programmable, non-programmable and line-voltage thermostats. Check your system type (conventional, heat pump, millivolt or line voltage) and whether you have a C-wire.

Specifications

Part Number TH8321R1001/U
Application 2H/2C Conventional Systems, 3H/2C Heat Pumps with auxiliary heat, Dual Fuel, Humidifier, dehumidifier, or ventilator control
Thermostat Type Programmable, Digital, Low Voltage, RedLINK
Smart Home Integration No
Display Type Touch Screen
Display Size 10 sq in
Touchscreen Yes
Display Language English
Displayed Information Indoor Temperature, Indoor Humidity, Outdoor Temperature, Outdoor Humidity, Time, Status Display
IAQ Capability Humidification, Dehumidification, Ventilation
Modes of Operation Heat, Off, Cool, Auto, Emergency Heat except model TH8110R1008
Program Type 7-Day Programmable, Manual / Not Programmed
Energy Star Certified Yes
Alerts and Reminders Customizable Service Reminders
Power Supply Battery, Hardwired
Battery Type Alkaline
Power Source Hardwired, Battery Operated
Number of Batteries 4
Battery Life 1 Years
Battery Size AA
Manufacturer Warranty 5 Years
Includes VisionPRO® 8000 Thermostat, Wall anchors, Screws, Literature
For Use With Works standalone or with optional THM5421R1021 Equipment Interface Module and RedLINK® 2.0 accessories
Communication Type RedLINK, WiFi
WiFi No
WiFi Specifications Internet Gateway THM6000R7001/U Provides WiFi Capabilities
Z-Wave No
Z-Wave Specifications Not Applicable
RedLINK Yes
Color Arctic White
Sensor Type Thermistor
Ambient Operating Temperature (Max) 120 °F, 49 °C
Ambient Operating Temperature (Min) 32 °F, 0 °C
Operating Relative Humidity (Max) 90% Non-condensing
Operating Relative Humidity (Min) 5% Non-condensing
Backlight Options Adjustable
Fan Function On, Auto, Circulating
Clock Type Year Clock
Demand Response No
Electrical Connection Type Screw terminals
Humidity Set point (Max) Heating: 60% RH, Cooling: 80% RH
Humidity Set point (Min) Heating: 10% RH, Cooling: 40% RH
Mounting Type Horizontal Mount
Power Supply Frequency 50 Hz, 60 Hz
Set point Temperature (Max) Heat: 90 °F, Heat: 32 °C, Cool: 99 °F, Cool: 37 °C
Set point Temperature (Min) Heat: 40 °F, Heat: 5 °C, Cool: 50 °F, Cool: 10 °C
Mounting Location Wall
Product Height 4.63 in, 118 mm
Product Width 4.94 in, 126 mm
Product Depth 1.13 in, 29 mm
Hazmat Information Lithium metal button cells only contained in equipment, Excepted per PI970
Features ENERGY STAR Certified, Backlit Display, Filter Change Reminder, Humidity Sensor, Indoor Air Quality Control, Touchscreen Display
UPC 085267770439
Country of Origin MX

Ratings & details

  • Portable Comfort Control (REM5000R1001/U)

Manufacturer documents
