TH109PROPLUS/U Non-Programmable Line Voltage Thermostat, 3000 W
- Part #
- TH109PROPLUS/U
- UPC
- 194159005914
$61.61
Available · ships in 1–2 business days
Free shipping to the contiguous US. No minimum.
Delivery estimate
- Order
- Ships
- Arrives
Estimate for ground shipping within the contiguous US.
- Connection
- Leadwire
- Finish
- White
Full specifications 2 manufacturer documents
- 30-day returnsWithin 30 days, in the original packaging
- Help from real peopleCall or email us before or after you order
- Secure checkoutCard details never touch our servers
Product details
TH109PROPLUS/U — Non-Programmable Line Voltage Thermostat, 3000 W.
Smart Wi-Fi, programmable, non-programmable and line-voltage thermostats. Check your system type (conventional, heat pump, millivolt or line voltage) and whether you have a C-wire.
Specifications
| Part Number | TH109PROPLUS/U |
|---|---|
| Application | 24 V AC Systems |
| Thermostat Type | Non programmable |
| Smart Home Integration | No |
| Display Size | 6.89 sq in |
| Displayed Information | Indoor Temperature, Fan, Heating Intensity Indicator |
| Energy Star Certified | No |
| Power Supply | Hardwired |
| Frequency | 60 Hz |
| Manufacturer Warranty | 3 Years |
| Includes | Thermostat, Installation Guide, Wireless Sensor, Screws, Anchors, Wire Labels |
| RedLINK | No |
| Color | White |
| Sensor Type | Thermistor |
| Ambient Operating Temperature (Max) | 102 °F, 39 °C |
| Ambient Operating Temperature (Min) | 37 °F, 2.8 °C |
| Differential Temperature | ± 1 °F, ± 0.5 °C |
| Temperature Accuracy | 0.27 °F, 0.15 °C |
| Connection Type | Leadwire |
| Electrical Connection Type | UWP Mounting System |
| Interstage Differential Temperature | 1 to 1.5 °F, 0.5 to 1°C |
| Mounting Type | Vertical Mount |
| Set point Temperature (Max) | 85 °F, 30 °C |
| Set point Temperature (Min) | 40 °F, 5 °C |
| Shipping and Storage Temperature (Max) | 120 °F, 49 °C |
| Shipping and Storage Temperature (Min) | 20 °F, -29 °C |
| Switch Action | SPST |
| Switch Type | Triac |
| Product Height | 4.9 in, 124 mm |
| Product Length | 4.5 in, 115 mm |
| Product Width | 1 in, 26 mm |
| Product Depth | 1, 26 |
| UPC | 194159005914 |
| Country of Origin | CN |
