S87C1030/U Direct Spark Ignition Control, Two Rod, with 21 Second Trial and Lockout Time
- Part #
- S87C1030/U
- UPC
- 085267085250
$261.51
Available · ships in 1–2 business days
Free shipping to the contiguous US. No minimum.
Delivery estimate
- Order
- Ships
- Arrives
Estimate for ground shipping within the contiguous US.
Full specifications 1 manufacturer document
Gas, electrical and venting work should be done by a licensed professional.
- 30-day returnsWithin 30 days, in the original packaging
- Help from real peopleCall or email us before or after you order
- Secure checkoutCard details never touch our servers
Product details
S87C1030/U — Direct Spark Ignition Control, Two Rod, with 21 Second Trial and Lockout Time.
Gas valves, ignition modules, igniters, flame sensors, thermocouples and oil primary controls. Match fuel type, voltage and inlet/outlet size.
Specifications
| Part Number | S87C1030/U |
|---|---|
| Type | Direct spark ignition control |
| Trial for ignition | 21 s |
| UPC | 085267085250 |
| Application | Low voltage, solid state, direct spark ignition control module for gas-fired furnaces, boilers and heating appliances |
| Type of Fuel | Natural Gas, LPG |
| Ignition Type | Direct Spark |
| Ignition Source | Internal high voltage spark generator |
| Ignition Between Trail Time | Lockout |
| Ignition Sequence | Lockout |
| Ignition Trials To Lockout | 1 |
| Pre-Purge | None |
| Lockout Timing | 21 sec |
| Flame Failure Response Time | 0.8 sec. @ 5.0 microamp |
| Flame Sense | Two Rod |
| Typical Ignition Hardware | Q347A, Q354, Q366 |
| Igniter-Sensor Rod | Dual |
| Typical Gas Control | VR8205, VR8305 |
| Frequency | 60 Hz |
| Operating Voltage | 25 V AC |
| Product Height | 5.25 in, 133 mm |
| Product Width | 4.06 in, 103 mm |
| Ambient Operating Temperature (Max) | 175 °F, 79 °C |
| Ambient Operating Temperature (Min) | 40 °F, -40 °C |
