RC840T-120/U Electromechanical Relay with 24 V to 120 V Transformer
- Part #
- RC840T-120/U
- UPC
- 775264840005
- Type
- Relays
$82.13
Available · ships in 1–2 business days
Free shipping to the contiguous US. No minimum.
Delivery estimate
- Order
- Ships
- Arrives
Estimate for ground shipping within the contiguous US.
Full specifications 2 manufacturer documents
Gas, electrical and venting work should be done by a licensed professional.
- 30-day returnsWithin 30 days, in the original packaging
- Help from real peopleCall or email us before or after you order
- Secure checkoutCard details never touch our servers
Product details
RC840T-120/U — Electromechanical Relay with 24 V to 120 V Transformer.
Aquastats, switching relays, transformers, contactors, sensors and switches that tie thermostats, boilers and pumps together.
Specifications
| Part Number | RC840T-120/U |
|---|---|
| Type | General purpose relay |
| Voltage | 24 V |
| Internal transformer | Yes |
| UPC | 775264840005 |
| Application | Control a line voltage resistive load from a low voltage thermostat |
| Approvals and Standards | UL Approved |
| Compatible With | 2 and 3 wire thermostats |
| For Use With | TH140-28-01-B, TH135-01-B, TH114-A-024T, TH115-A-024T |
| Includes | Lock-nut |
| Operating Frequency | 60 Hz |
| Switch Action | On/Off Switching |
| Compatible Thermostat | Compatible with 24 V thermostats with 2-wire connections (R, W) or 3-wire connections (R, W, C) |
| Manufacturer Warranty | 3 Years |
| Ambient Operating Temperature (Min) | 4 °F, -20 °C |
| Ambient Operating Temperature (Max) | 140 °F, 60 °C |
| Product Height | 3.22 in, 82 mm |
| Product Width | 2.28 in, 58 mm |
