R841D1036/U 24 V SPST Switching Electric Heater Relay
- Part #
- R841D1036/U
- UPC
- 085267128711
- Type
- Relays
$85.94
Available · ships in 1–2 business days
Free shipping to the contiguous US. No minimum.
Delivery estimate
- Order
- Ships
- Arrives
Estimate for ground shipping within the contiguous US.
Full specifications 2 manufacturer documents
Gas, electrical and venting work should be done by a licensed professional.
- 30-day returnsWithin 30 days, in the original packaging
- Help from real peopleCall or email us before or after you order
- Secure checkoutCard details never touch our servers
Product details
R841D1036/U — 24 V SPST Switching Electric Heater Relay.
Aquastats, switching relays, transformers, contactors, sensors and switches that tie thermostats, boilers and pumps together.
Specifications
| Part Number | R841D1036/U |
|---|---|
| Type | Heating relay |
| Switching | SPST |
| Voltage | 24 V |
| UPC | 085267128711 |
| Application | SPST switching Electric Heater Relay |
| Approvals and Standards | UL Component Recognized: File No.E47434, Guide No. XAPX, CSA Certified |
| Includes | Integral transformer, Enclosure with Conduit brushing |
| Coil Rating Voltage | 24 V ac |
| Coil Connection Type | Leadwire |
| Number of Poles | 1 Pole |
| Operating Frequency | 50 Hz, 60 Hz |
| Power Supply Frequency | 50 Hz, 60 Hz |
| Switch Action | SPST |
| Manufacturer Warranty | 1 Year |
| Ambient Operating Temperature (Min) | 20 °F, -29°C |
| Ambient Operating Temperature (Max) | 150 °F, 66 °C |
| Product Height | 3.87 in, 98 mm |
| Product Length | 1.5 in, 38 mm |
| Product Width | 2.81 in, 71 mm |
