R24BA1006/U Heat Sequencer, 2 Switches, On 1–20 sec, Off 40–110 sec
- Part #
- R24BA1006/U
- UPC
- 085267277921
- Type
- Relays
$32.37
Available · ships in 1–2 business days
Free shipping to the contiguous US. No minimum.
Delivery estimate
- Order
- Ships
- Arrives
Estimate for ground shipping within the contiguous US.
Full specifications 3 manufacturer documents
Gas, electrical and venting work should be done by a licensed professional.
- 30-day returnsWithin 30 days, in the original packaging
- Help from real peopleCall or email us before or after you order
- Secure checkoutCard details never touch our servers
Product details
R24BA1006/U — Heat Sequencer, 2 Switches, On 1–20 sec, Off 40–110 sec.
Aquastats, switching relays, transformers, contactors, sensors and switches that tie thermostats, boilers and pumps together.
Specifications
| Part Number | R24BA1006/U |
|---|---|
| Application | Electric Heat |
| Approvals and Standards | UL Approved File: 237660 |
| Contact Rating | 25 A at 120 or 240 V, 12.5 Amps at 480 V |
| Electrical Connection Size | 1/4 in |
| Electrical Connection Type | Solder or screw type quick connect |
| Timing Delay | On-timing - 1 to 20 sec (first & second switch), Off-timing- 40 to 110 sec (first & second switch) |
| Ambient Operating Temperature (Min) | 40 °F, -40 °C |
| Ambient Operating Temperature (Max) | 165 °F, 73.8 C |
| UPC | 085267277921 |
| Country of Origin | CN |
| Product Features | Solid-state PTC Heaters, Shock and vibration resistant |
Ratings & details
- Solid-state PTC Heaters
- Shock and vibration resistant
