NPF700-100U5CH Condensing Hydro Furnace, Upflow, 14,000-100,000 BTU, NG/LP Convertible

Part #
NPF700-100U5CH
$3,570.00

Available · ships in 1–2 business days

Ships by truck · free freight delivery. The carrier calls you to schedule delivery.

Full specifications

Gas, electrical and venting work should be done by a licensed professional.

  • 30-day returnsWithin 30 days, in the original packaging
  • Help from real peopleCall or email us before or after you order
  • Secure checkoutCard details never touch our servers
Need help matching a part?Call +1 (219) 319-0174 · Mon–Fri, 8 am – 5 pm ET

Product details

NPF700-100U5CH — Condensing Hydro Furnace, Upflow, 14,000-100,000 BTU, NG/LP Convertible.

Condensing, combi and cast iron boilers for hydronic heating, many with domestic hot water built in. Size from a heat-loss calculation, not the old boiler's rating.

Specifications

Part Number NPF700-100U5CH
Configuration Upflow
Gas input (heating) 14,000 - 100,000 BTU/h
AFUE 97%
Airflow Max heat 1,200 - 2,000 CFM; min heat 500 - 2,000 CFM; cooling 2,000 CFM
Nominal cooling capacity 2.0 - 5.0 ton at 400 CFM/ton; 2.0 - 5.5 ton at 350 CFM/ton
Blower 12.0" D x 12.0" W, 1.0 HP variable-speed ECM, 11.0 motor full load amps
External static pressure (heating) 0.1 - 0.8" WC
Gas supply pressure Natural gas 3.5 - 10.5" WC; propane 8 - 13" WC
Connections 1/2" NPT gas inlet; 1/4" NPT cold water inlet; 3/4" NPT condensate outlet
Power supply 120V AC, 60 Hz; 14.3 A max current; 20 A breaker; 12 AWG wire
Venting Forced draft, direct or non-direct vent; 2" or 3" PVC, CPVC, PP or stainless steel; max vent length 70 ft (2") or 140 ft (3"); 0" clearance to combustibles
Dimensions 21.0" W x 34.5" H x 31.0" D
Shipping Weight 167.6 lb

Ratings & details

  • Works with single- or two-stage thermostats
