NPF700-060U3BH — Condensing Hydro Furnace, Upflow, 9,000-60,000 BTU, NG/LP Convertible.

Condensing, combi and cast iron boilers for hydronic heating, many with domestic hot water built in. Size from a heat-loss calculation, not the old boiler's rating.

Specifications

Part Number NPF700-060U3BH
Configuration Upflow
Gas input (heating) 9,000 - 60,000 BTU/h
AFUE 97%
Airflow Max heat 720 - 1,200 CFM; min heat 450 - 1,200 CFM; cooling 1,200 CFM
Nominal cooling capacity 1.5 - 3.0 ton at 400 CFM/ton; 1.5 - 3.5 ton at 350 CFM/ton
Blower 12.0" D x 10.0" W, 1.0 HP variable-speed ECM, 7.6 motor full load amps
External static pressure (heating) 0.1 - 0.8" WC
Gas supply pressure Natural gas 3.5 - 10.5" WC; propane 8 - 13" WC
Connections 1/2" NPT gas inlet; 1/4" NPT cold water inlet; 3/4" NPT condensate outlet
Power supply 120V AC, 60 Hz; 10.9 A max current; 15 A breaker; 14 AWG wire
Venting Forced draft, direct or non-direct vent; 2" or 3" PVC, CPVC, PP or stainless steel; max vent length 70 ft (2") or 140 ft (3"); 0" clearance to combustibles
Dimensions 17.5" W x 34.5" H x 31.0" D
Shipping Weight 145 lb

Ratings & details

  • Works with single- or two-stage thermostats
