MX128LF/U 1 1/4 in NPT Mixing Valve LF

MX128LF/U 1 1/4 in NPT Mixing Valve LF

Part #
MX128LF/U
UPC
085267358972
$1,105.61

Available · ships in 1–2 business days

Free shipping to the contiguous US. No minimum.

Size
1-1/4 in
Material
Teflon-coated, Bronze
Connection
NPT
Finish
Metallic

Full specifications 5 manufacturer documents

WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov.

Gas, electrical and venting work should be done by a licensed professional.

  • 30-day returnsWithin 30 days, in the original packaging
  • Help from real peopleCall or email us before or after you order
  • Secure checkoutCard details never touch our servers
Need help matching a part?Call +1 (219) 319-0174 · Mon–Fri, 8 am – 5 pm ET

Product details

MX128LF/U — 1 1/4 in NPT Mixing Valve LF.

Thermostatic mixing valves blend hot and cold to a set outlet temperature, protecting against scalding while letting you store water hotter. Lead-free models are for potable water; heating-only models are for hydronic loops.

Specifications

Part Number MX128LF/U
Type Thermostatic mixing valve
Size 1-1/4 in
Connections NPT
Lead free Yes
UPC 085267358972
Controlled Media Potable Water, Non Potable Water
Re-Circulation Yes
Approvals and Standards ASSE 1017 Certified, CSA Listed, NSF/ANSI 61 Certified
Color Metallic
Includes (3) 1 1/4 in Gaskets, 1/2 in BSP recirculation adapter, Check Valves on Hot and Cold Inlets
Product Length 7.7 in, 196 mm
Product Weight 6.4 lb, 2.9 kg
Manufacturer Warranty 1 Year
Adjustment Means Allen Key
Differential Pressure (Max) 7 psi, 48.3 kPa
Flex Connector Included No
Flow Coefficient 9.3 Cv
Flow Rate (Min) 2.5 gpm, 9.5 lpm
Media Temperature (Max) 221 °F, 105 °C
Number of Check Valves 2
Operating Mixing Temperature (Min) 113 °F, 45 °C
Operating Mixing Temperature (Max) 149 °F, 65 °C
Operating Pressure (Max) 150 psi, 1034 kPa
Seal Material Gun Metal
Valve Body Material Teflon-coated, Bronze
Accessories MX 050-RP/U
Connection Size 1 1/4 in
Connection Type NPT
Nominal Diameter DN32
Number of Connections 4
