MPA5240 0050301 5/8" x 3/8" ACR Press Fitting - Coupling (Reducing)

MPA5240 0050301 5/8" x 3/8" ACR Press Fitting - Coupling (Reducing)

Part #
MPA5240 0050301
$46.42

Available · ships in 1–2 business days

Free shipping to the contiguous US. No minimum.

Size
5/8" x 3/8"

Full specifications

  • 30-day returnsWithin 30 days, in the original packaging
  • Help from real peopleCall or email us before or after you order
  • Secure checkoutCard details never touch our servers
Need help matching a part?Call +1 (219) 319-0174 · Mon–Fri, 8 am – 5 pm ET

Product details

MPA5240 0050301 — 5/8" x 3/8" ACR Press Fitting - Coupling (Reducing).

High-pressure press fittings for refrigerant lines on ACR copper, rated for the pressures of modern refrigerants.

Specifications

Part Number MPA5240 0050301
Size 5/8" x 3/8"
Type Reducing coupling, press x press
Application ACR
Maximum operating pressure 700 psi (48 bar)
Operating temperature 40°F to 250°F (-40°C to 120°C)
Fitting material Copper
Seal HNBR O-ring

Ratings & details

  • Secure, permanent 3-point press
  • Rated to 700 psi maximum operating pressure
