EA79A1004 Industrial Automatic Air Vent
- Part #
- EA79A1004
- UPC
- 085267044134
- Type
- Air Vents
$83.46
Available · ships in 1–2 business days
Free shipping to the contiguous US. No minimum.
Delivery estimate
- Order
- Ships
- Arrives
Estimate for ground shipping within the contiguous US.
- Size
- 3/4 in, 1/2 in, 19.05 mm, 12.7 mm
- Material
- Brass
- Connection
- Female NPT, Male NPT
- Finish
- Black, Metallic, Red
Full specifications 3 manufacturer documents
Gas, electrical and venting work should be done by a licensed professional.
- 30-day returnsWithin 30 days, in the original packaging
- Help from real peopleCall or email us before or after you order
- Secure checkoutCard details never touch our servers
Product details
EA79A1004 — Industrial Automatic Air Vent.
Air and dirt separators, hydraulic separators, magnetic filters, vents, expansion tanks, fill systems and system treatment that protect a hydronic loop.
Specifications
| Part Number | EA79A1004 |
|---|---|
| Type | Automatic air vent |
| Connections | 3/4 in male NPT pipe thread with 1/2 in female NPT pipe thread |
| Connection size | 3/4 in |
| Maximum temperature | 250 F |
| Maximum pressure | 150 psi |
| Dimensions | 5 in long x 1 7/8 in diameter |
| Application | Air Ventilation, Hydronic Heating Systems, Hydronic Cooling Systems |
| Controlled Media | Non Potable Water |
| Manufacturer Warranty | 1 Year |
| Color | Black, Metallic, Red |
| Compatible With | Hydronic Heating and Cooling Systems |
| For Use With | P79B1003 Cover Assembly, Q122A1001 Safe Waste Connector, 204992 Vent Cap |
| Media Temperature (Max) | 250 °F, 120 °C |
| Bottom Connection | Yes |
| Connection Type | Female NPT, Male NPT |
| Pipe Size | 3/4 in, 1/2 in, 19.05 mm, 12.7 mm |
| DN Size | DN20, DN15 |
| Operating Pressure (Max) | 150 psi, 1034 kPa |
| Product Diameter | 1 7/8 in, 48 mm |
| Product Height | 5 in, 128 mm |
| Product Length | 5 in, 128 mm |
| Seal Material | Synthetic Rubber |
| Float Material | Polyphenylene Sulfide (PPS) |
| Body Material | Brass |
