AT20A1123/U Foot Mounted 120 V AC Transformer with 9 in Leadwires
- Part #
- AT20A1123/U
- UPC
- 085267035613
- Type
- Transformers
$49.43
Available · ships in 1–2 business days
Free shipping to the contiguous US. No minimum.
Delivery estimate
- Order
- Ships
- Arrives
Estimate for ground shipping within the contiguous US.
Gas, electrical and venting work should be done by a licensed professional.
- 30-day returnsWithin 30 days, in the original packaging
- Help from real peopleCall or email us before or after you order
- Secure checkoutCard details never touch our servers
Product details
AT20A1123/U — Foot Mounted 120 V AC Transformer with 9 in Leadwires.
Aquastats, switching relays, transformers, contactors, sensors and switches that tie thermostats, boilers and pumps together.
Specifications
| Part Number | AT20A1123/U |
|---|---|
| Type | Control transformer |
| Rating | 20 VA |
| Primary | 120 V |
| Secondary | 24 Vac |
| Mounting | Foot |
| Leadwires | 9 in |
| UPC | 085267035613 |
| NEMA Rating | Yes |
| Primary Connection Size | 9 in, 229 mm |
| Primary Connection Type | Leadwires: Black and White |
| Primary Input Voltage | 120 V ac |
| Secondary Connection Size | 9 in, 229 mm |
| Secondary Connection Type | Color coded primary and secondary Leadwires |
| Secondary Open Circuit Voltage | 26.5 V.O.C. |
| VA Rating | 19 VA |
| Frequency | 50 Hz; 60 Hz |
| Approvals and Standards | UL Component Recognized, CSA Certified, NEC Class 2 |
| Ambient Operating Temperature (Max) | 105 °F, 41 °C |
| Ambient Operating Temperature (Min) | 20 °F, -29 °C |
| Product Height | 2 in, 50.5 mm |
| Product Width | 2.25 in, 57 mm |
