AM100-002RP/U Rebuild Kit for AM Standard Series Mixing Valves

AM100-002RP/U Rebuild Kit for AM Standard Series Mixing Valves

Part #
AM100-002RP/U
UPC
085267824675
$53.96

Available · ships in 1–2 business days

Free shipping to the contiguous US. No minimum.

Full specifications 5 manufacturer documents

Gas, electrical and venting work should be done by a licensed professional.

  • 30-day returnsWithin 30 days, in the original packaging
  • Help from real peopleCall or email us before or after you order
  • Secure checkoutCard details never touch our servers
Need help matching a part?Call +1 (219) 319-0174 · Mon–Fri, 8 am – 5 pm ET

Product details

AM100-002RP/U — Rebuild Kit for AM Standard Series Mixing Valves.

Thermostatic mixing valves blend hot and cold to a set outlet temperature, protecting against scalding while letting you store water hotter. Lead-free models are for potable water; heating-only models are for hydronic loops.

Specifications

Part Number AM100-002RP/U
Type Mixing valve service part
UPC 085267824675
Shipping Weight 0.2 lb
Controlled Media Potable Water, Non Potable Water
Re-Circulation No
Includes Element, Spring, Plug Assembly
Manufacturer Warranty 1 Year
Cold Inlet Temperature (Min) 39 °F, 4 °C
Cold Inlet Temperature (Max) 80 °F, 27 °C
Hot Inlet Temperature (Min) 120 °F, 49 °C
Hot Inlet Temperature (Max) 180 °F, 82 °C
Lead Free No
Operating Mixing Temperature (Min) 70 °F, 21 °C
Operating Mixing Temperature (Max) 145 °F, 63 °C
Operating Pressure (Max) 150 psi, 1034 kPa
Valve Body Pattern Straight Through
